1) Length:600mm 908mm
2) Width: 450mm
3) Special heating exchange area: 125 square meter / cubic meter
4) Thickness: 1.8mm
5) Conection: wedged joint
6) Maximum total suspended solid: 300 ppm continuoous operation and can be bear under 500 ppm within 10 hours
7) Usage life: ≥ 20 years
Wusen environmentally friendly plastic deodorization evaporative pad is injection molded from a patented original plastic mold. It adopts a high-standard formula with the advantages of corrosion resistance, strong toughness, wind resistance and long service life. And the flame retardant cooling pad can be customized according to the use scenario.
| Product name | Plastic deodorization evaporative |
| Monolithic height | cooling pad |
| Assembly requirements | height:600mm |
| Forming specific ation | Clip assembly in place |
| Heat resistance | thick:450mm Any width assembly |
| Drop hammer impact | 112°C No embrittlement within 24hours |
| Yield stress | 6.86/7.61 |
| Vicat softening | 35.73 |
| temperature | 148°C |
| Specific surface area | 125m2/m3 |
| Gas-liquid ratio | 0.1-0.3L/m3,1.5m/s wind speed < 15Pa |
| Material quality | New PP raw materials |
| Density | 21.3kg/m |
| Oper ating | -40°C-90°C |
| temperature | Humidity has no effect |
| Oper ating humidity | V0/V2/Non flammable |
| Flame retardancy | Inclined channel |
| By | splash |
| Heating change rate | <0.2% |
| Channel width | 20mm |
| Por osity | > 97% |
| Service life | 15 years |
